Adobe Experience Manager 6 with a MongoDB Setup
With AEM 6 the persistence layer which is used to store content, configurations, and program code, is called a MicroKernel (MK). AEM 6 introduced a new MicroKernel and here's what you should know.
AEM 6 introduced a new MicroKernel (MongoMK) which allows the use of MongoDB as a repository. Further MicroKernels may be added along the line but are not fully confirmed yet. In this article we will be looking at a very basic local MongoDB setup.
A simple and local MongoDB with AEM
Requirements:
- Linux or Mac
- Java 7 (preferably JDK and possibly from Oracle so you can make full use of JMX)
- An AEM 6 license
- An AEM 6 crx-quickstart jar
- The mongodb binaries (linked below)
Follow the steps below to get an AEM author (or publish) up and running using a local MongoDB
1. Prepare a folder structure (sample) as below
./aem_600_mongodb<br>
./aem_600_mongodb/mongodb<br>
./aem_600_mongodb/mongodb/data<br>
./aem_600_mongodb/mongodb/logs
2. Download MongoDB for Mac OSX or other OS (configs in this guide also work with Linux)
http://www.mongodb.org/downloads
3. extract the packages content directly into the mongodb directory as created under point 1. -> ( ./aem_600_mongodb/mongodb/bin should then exist )
4. in your mongodb directory, parallel to the data & logs & bin directory create the mongod.cfg file
mongod.cfg
bind_ip = 127.0.0.1<br>
port = 27017<br>
quiet = false<br>
dbpath = ../data<br>
logpath = ../logs/mongod.log<br>
logappend = true<br>
journal = true<br>
directoryperdb = true<br>
rest = true<br>
httpinterface = true<br>
5. now place your license.properties & AEM 6 quickstart jar in your base directory (in this case ./aem_600_mongodb)
6. extract the AEM 6 jar file (java -jar aem-6.0.0.20140515.jar -unpack)
7. edit the start script under ./aem_600_mongodb/crx-quickstart/bin and add the following properties
CQ_RUNMODE='author,crx3mongo' -> crx3mongo is added here<br>
CQ_JVM_OPTS='-server -Xmx1024m -XX:MaxPermSize=256M -Djava.awt.headless=true -Doak.mongo.uri=mongodb://localhost:27017' -> -Doak.mongo.uri=mongodb://localhost:27017 is added here
8. once the above steps are completed go to your bin directory in your mongodb directory and start mongo db & tail the log
./mongod --config ../mongod.cfg && tail -f ../logs/mongod.log
9. now start your AEM from the ../crx-quickstart/bin directory and tail the log
./start && tail -f ../error.log
10. once your AEM is started and everything has been created you got an AEM running on MongoDB
11. for administration purposes have a look at using the robomongo app: http://robomongo.org/
The Adobe documentation and MongoDB documentation is your best bet for further details.
Setup a replica set
A. Change mongod.cfg
bind_ip = mongotest
port = 27017
quiet = false
dbpath = ../data
logpath = ../logs/mongod.log
logappend = true
journal = true
directoryperdb = true
rest = true
httpinterface = true
B. Modify /etc/hosts
172.32.10.10 mongotest
C. Start Mongo with Option --replSet
./mongod --replSet "rs0" --config ../mongod.cfg
D. Open Mongo Console
./mongo 192.168.36.72
rs.initiate()
rs.conf()
{
"_id" : "rs0",
"version" : 1,
"members" : [
{
"_id" : 1,
"host" : "mongotest:27017"
}
]
}
rs.add(mongotest2)
rs.status()
{
"set" : "rs0",
"date" : ISODate("2014-07-21T16:45:15Z"),
"myState" : 1,
"members" : [
{
"_id" : 0,
"name" : "mongotest:27017",
"health" : 1,
"state" : 1,
"stateStr" : "PRIMARY",
"uptime" : 5559,
"optime" : Timestamp(1405961115, 1),
"optimeDate" : ISODate("2014-07-21T16:45:15Z"),
"electionTime" : Timestamp(1405955596, 2),
"electionDate" : ISODate("2014-07-21T15:13:16Z"),
"self" : true
},
{
"_id" : 3,
"name" : "mongotest2:27017",
"health" : 1,
"state" : 2,
"stateStr" : "SECONDARY",
"uptime" : 3445,
"optime" : Timestamp(1405961115, 1),
"optimeDate" : ISODate("2014-07-21T16:45:15Z"),
"lastHeartbeat" : ISODate("2014-07-21T16:45:15Z"),
"lastHeartbeatRecv" : ISODate("2014-07-21T16:45:15Z"),
"pingMs" : 4,
"syncingTo" : "mongotest:27017"
},
],
"ok" : 1
}
**Failover logic with a MongoDB replica set **
- The logic for the actual failover needs to be defined in a separate layer, in this case in the Load Balancer.
- This makes the setup a bit more complex but also offers you a bit more flexibility as you can do some fancy setups.
- To make it work overall you are required to have a virtual IP located in front of the AEM and a separate virtual IP in front of the Mongo Replica Set.
- In general the logic won't differ too much from a CRX2 cluster setup except that you introduce a second Loadbalancer, as seen above.
- This one sits between the AEM and MongoDB to handle connections in case a Primary node drops out of the pool.
- In any case you are required to also have an Arbiter node or a 3rd MongoDB also acting as a secondary. This is required due to the nature of the MongoDB Primary node election process.
